Features
Electrical Performance
Inverter: Full bridge topology
SCH series inverter surges 2×rated power to support the induction loads such as air compressor, residential refrigerator, blender, or coffee maker.
Operating the heater blower and microwave would draw more than the rated power to boost the appliances. With a strong inside building and fast cooling fans, the SCH inverter gives excellent performance operating.
The peak efficiency of the SCH series is 93.5%
Applications
Power tools- circular saws, drills, grinders, sanders, buffers, weed, hedge trimmers, air compressor, etc.
Office equipment- computers, printers, monitors, facsimile machines, scanners, etc.
Household appliances- vacuum, fans, lights, TV, refrigerator, microwave, coffee machine, toaster, blender and etc.
Industrial equipment- metal halide lamp, high-pressure sodium lamp and etc.
NOTE, The inverter working time with 100% loads cannot be over 90 minutes.
Remote controller
The SCH600, SCH1000, SCH1500, SCH2000, and SCH3000 can connect to an optional remote (P/No. CR10), which will allow the inverter to be turned on/off remotely. Ideal for use in caravans, motor homes, and boats.
Specifications
| Power input&Output |
SCH1500 |
| Output Power |
1500W |
| Surge Power |
3000W |
| Idle power |
9W |
| DC Input Voltage |
12/24/48VDC |
| DC Input Regulation |
10.5-15VDC(*2 for 24vdc, *4 for 48vdc) |
| Output Voltage |
100/110/120VAC
+/-3%;220/230/240VAC+/-5% |
| Output Frequency |
50/60HZ+/-0.05% |
| Output Waveform |
TruesinewaveTHD<3% |
| Power Factor |
0.8-1 |
| Efficiency |
110V 93% |
| 220V 93% |
| Control&
Signal indicates |
|
| Fault indication |
RedLEDlightandbuzzalarm |
| Work Indication |
GreenLEDlight |
| Remote Control |
CR10 |
| Battery type |
AGM,Seal lead acid,Gel,Open lead acid,LiFe04 |
| Protection |
Overload,Over/under input
voltage,
Over temperature, Short circuit |
| Safety |
AS/NZS4763:2011,
UL458,LVD(EN60950) |
| General parameter |
|
| Operating Temp |
-5-40℃ |
| Working Humidity |
20-90%RH |
| Storage Temp |
-30-70
℃ |
| Cooling |
Automatictemp-controlfans |
| Weight(kg) |
3.5 |
| Size(mm) |
170*357*96 |
