Features
The SCH power inverter gives the perfect performance for running loads from household appliances to office devices with the pure sine wave output, no matter coffee machine, microwave, TV, satellite, printer, or other heavy-duty equipment.
SCH600 models have FCC class A regulation to eliminate interference potential with other devices; This inverter can be easily installed to fit into any compartment.
Product Features
- Regulated by UL458 and CSA C22.2, CE under EN55022:2006+A1:2007 standards
- Pure sine wave output runs all loads from households appliances to office equipment
- Independent heatsink design to decrease the temperature of the main case
- High overload capacity allows high surge power to operate induction loads
- External LED remote controller with 5 meters remote wire
- 24 months warranty
Protection
- Battery DC over voltage and low voltage protection
- Short circuit protection
- Over-temperature protection
- Overload protection
| Model |
SCH600 |
| Output Power |
600W |
| Surge Power |
1200W |
| Idle power |
3W |
| DC Input Voltage |
12VDC |
| DC Input Regulation |
10.5-15 VDC |
| Output Voltage |
100/110/120VAC +/- 3%; 220/ 230/ 240VAC +/- 5% |
| Output Frequency |
50/60HZ +/- 0.05% |
| Output Waveform |
True sine wave THD<3% |
| Power Factor |
0.8-1 |
| Efficiency |
110V 90% |
| 220V 92% |
| Control & Signal indicates |
|
| Fault indication |
Red LED light and buzz alarm. |
| Work Indication |
Green LED light |
| Remote Control |
CR10 or CR11 (work with DBS battery isolator) |
| Battery type |
AGM, Seal lead-acid, Gel, Open lead acid, LiFe04 |
| Protection |
Overload,Over/under input voltage, |
| Over temperature, Short circuit |
| Safety |
AS/NZS 4763:2011, UL458, LVD(EN60950) |
| General parameter |
|
| Operating Temp |
-5-40℃ |
| Working Humidity |
20-90% RH |
| Storage Temp |
-30-70 ℃ |
| Cooling |
Automatic temp-control fans |
| Weight (kg) |
1.5 |
| Size (mm) |
150*237*79 |
