Features
CCT series pure sine wave inverter charger is the combination of an inverter, battery charger, and AC auto-transfer switch. This complete system with a peak conversion efficiency of 88%.
CCT is the inverter charger with a backup UPS function. When utility AC power cuts off, the transfer relay is de-energized, and the load is transferred to the inverter o|uput. Once the qualified AC utility power is restored, the relay will be energized, and the load is automatically reconnected to the AC utility.
CCT series inverter charger unit is easily customized to battery priority via a DIP switch which helps extract maximum power from the battery in renewable energy systems. Therefore CCT inverter charger is suitable for renewable energy systems, RV, marine, and emergency appliances.
Application:
Power tools- circular saws, drills, grinders, sanders, buffers, weed, hedge trimmers, air compressors and etc.
Office equipment- computers, printers, monitors, facsimile machines, scanners and etc.
Household appliances- vacuum, fans, lights, TV, refrigerator, microwave, coffee machine, toaster, blender and etc.
Industrial equipment- metal halide lamp, high-pressure sodium lamp and etc.
NOTE, The inverter/charger working time with full loads cannot be over 60 minutes.
Specification:
output power: 2000w
surge power: 6000w
DC input voltage: 12VDC
Output voltage: 100/110/120 VAC±5%
Output Frequency: 50/60HZ ±0.5%
Output Waveform: True sine wave (THD<3%)
Efficiency: 88%
MAX bypass current: 25A
Remote Control: CR10;PTM-12
Dip switch: Output frequency; AC output voltage； DC/AC priority
Network function(optional): TCP/IP
Battery type: LiFeP04, Gel, AGM, Wet or customized
Weight (kg/lbs): 17/37
Size(mm/inch): 450x225x180/18x9x7
Protection:
1. Input AC over-voltage and low voltage protection
2. Battery DC over voltage and low voltage protection
3. Short circuit protection
4. Over-temperature protection
5. Overload protection
