LPT Series Pure Sine Wave Inverter Charger

LPT series 5000W

LPT Series Pure Sine Wave Inverter Charger - LPT5000W

Sample Title

Sample Text

LPT Series Pure Sine Wave Inverter Charger - LPT5000W

Sample Title

Sample Text

LPT Series Pure Sine Wave Inverter Charger - LPT5000W

Sample Title

Sample Text

LPT Series Pure Sine Wave Inverter Charger - LPT5000W

Sample Title

Sample Text

  1. LPT Series Pure Sine Wave Inverter Charger - LPT5000W
  2. LPT Series Pure Sine Wave Inverter Charger - LPT5000W
  3. LPT Series Pure Sine Wave Inverter Charger - LPT5000W
  4. LPT Series Pure Sine Wave Inverter Charger - LPT5000W
Ref: LPT5000W
● DC input voltage: 24v/48v

● AC output: 100-120v/210v-250v

● Peak power: 15000w

● Waveform: Pure Sine Wave

● Product description: low frequency single phase 5000w pure sine wave inverter charger 24v 48v dc to ac 110v 120v 220v 230v 240v power inverter 5kw
Would you like to know more?
Wholesale Enquiry

Features

Features

● Pure sine wave output, input & output fully isolation
● AC charger with 4-stage charge mode, up to 75A
● High-efficiency design up to 88 %, energy-saving mode
● Excellent loads with 3*rated start power
● 7 LED display shows the work and charging station
● The built-in LCD display, shows data of working
● Built-in AC bypass relay, UPS function
● Advanced microprocessor control
● Input polarity/UVP/OVP/OSP/OLP/OTP

● Remote control RJ11

Specification


Models LPT5000-124 LPT5000-148 LPT5000-224 LPT5000-248
OutputPower 5000W
SurgePower 15000W
DCInputVoltage 24VDC 48VDC 24VDC 48VDC
OutputVoltage 100/110/120VAC±5% 220/230/240VAC±3%
OutputFrequency 50/60Hz±0.5%
OutputWaveform Truesinewave(THD<5%)
PowerFactor 0.1~1
Efficiency 86% 88% 87% 90%
NoLoadPower <55W(Powersavingmode)
TransferTime <8ms
ACRange 90~135VAC/190~245VAC
VoltageRange 20.0~31.0VDC 42.0~62.0VDC 20.0~31.0VDC 42.0~62.0VDC
ChargeCurrent 65A 35A 70A 40A
FaultIndication LEDRed
RemoteControl PTM-10
Safety UL458 LVD(EN60950)
EMC FCCPart15ClassA CE(EN55022:2006+A1:2007)
OperatingTemp -20~50℃
WorkingHumidity 20~90%RH
StorageTemp -30~70℃
Cooling Automaticallycontrolledcoolingfan
Weight(kg) 45
Size(mm) 670*255*185(L*W*H)
Application

Solar power systems, Portable equipments, Power tools, Home and Office appliances
