Artículo |
Modelos |
CPS6000-1486M |
CPS6000-2246M |
CPS6000-2484 / 6M |
CPS6000-2489M |
Salida AC |
Potencia de salida |
6000 watts |
SurgePower |
18000W (≤2S) |
Frecuencia de salida |
50 / 60Hz ± 0.5% |
OutputWaveform |
Truesinewave (THD <3%) |
P · FAllowed |
COSθ-90 ° ~ COSθ + 90 ° |
Eficiencia |
86% |
88% |
87% |
90% |
DCINPUT |
Voltaje de entrada |
48VDC |
24VDC |
48VDC |
48VDC |
Rango de voltaje |
20.0 ~ 31.0VDC, * 2 para 48VDC / 21.0 ~ 32.0VDC, * 2 para48VDC |
Indicación de falla |
LEDRedandBuzzerAlarm |
Control remoto |
RS-232 / RJ45 (Opcional) |
Cargador |
ACRange |
184-253VAC / 154-253VAC |
100-135VAC / 90-135VAC |
Voltaje Rápido |
14.0 ~ 15.1V (* 2 para 24vdc, * 4 para 48vdc) |
FloatVoltage |
13.3-13.8V (* 2 para 24vdc, * 4 para 48vdc) |
Protección de sobrecarga |
15.7V para 12V (* 2 para 24vdc, * 4 para 48vdc) |
Corriente de Carga |
25A |
40A |
25A |
25A |
MPPTSolarCharger (opcional) |
solar panel max |
3120W |
2340W / 3120W |
1260W / 1680W |
2340W / 3120W |
Tensión nominal |
12V / 24V248VDCAuto |
Corriente nominal de carga |
60A |
45A / 60A |
45A / 60A |
45A / 60A |
DCLoadCurrent |
15A (MAX) |
Voltaje de entrada PV |
150VDC (MAX) |
Compensación temporal |
-13.2mv / ℃ (* 2for24vdc, 4for48vdc *) |
Derivación |
transfer time |
<8 ms |
InputVot.waveform |
UtilityACorGenerator (onda sinusoidal) |
Maxbypasscurrent |
80A / 40A |
Otros |
Humedad de Trabajo |
20-90% HR |
Seguridad y EMI |
UL458 |
LVD (EN60950) |
Workingtemp. |
-20 ~ 50 ℃ |
Temperatura de almacenamiento |
-30 ~ 70 ℃ |
Enfriamiento |
Ventilador de temperatura controlada |
Tamaño (mm) |
650 * 505 * 210 (L * W * H) |
Peso (kg) |
60 60 |
63 |
