Features
With the pure sine wave output, no matter coffee machine, microwave, TV, satellite, printer, or other heavy-duty equipment, the SCH power inverter gives the perfect performance for running loads from household appliances to office devices.
SCH300 models have FCC class A regulation to eliminate interference potential with other devices; This inverter can be easily installed to fit into any compartment.
Product Features
- Regulated by UL458 and CSA C22.2, CE under EN55022:2006+A1:2007 standards
- Pure sine wave output runs all loads from households appliances to office equipment
- Independent heatsink design to decrease the temperature of the main case
- High overload capacity allows high surge power to operate induction loads
- External LED remote controller with 5 meters remote wire
- 24 months warranty
Protection
- Battery DC over voltage and low voltage protection
- Short circuit protection
- Over-temperature protection
- Overload protection
| Model |
SCH300 |
| Output Power |
300W |
| Surge Power |
600W |
| Idle power |
3W |
| DC Input Voltage |
12VDC |
| DC Input Regulation |
10.5-15 VDC |
| Output Voltage |
100/110/120VAC +/- 3%; 220/ 230/ 240VAC +/- 5% |
| Output Frequency |
50/60HZ +/- 0.05% |
| Output Waveform |
True sine wave THD<3% |
| Power Factor |
0.8-1 |
| Efficiency |
110V 90% |
| 220V 92% |
| Control & Signal indicates |
|
| Fault indication |
Red LED light and buzz alarm. |
| Work Indication |
Green LED light |
| Remote Control |
CR10 or CR11 (work with DBS battery isolator) |
| Battery type |
AGM, Seal lead-acid, Gel, Open lead acid, LiFe04 |
| Protection |
Overload,Over/under input voltage, |
| Over temperature, Short circuit |
| Safety |
AS/NZS 4763:2011, UL458, LVD(EN60950) |
| General parameter |
|
| Operating Temp |
-5-40℃ |
| Working Humidity |
20-90% RH |
| Storage Temp |
-30-70 ℃ |
| Cooling |
Automatic temp-control fans |
| Weight (kg) |
1.5 |
| Size (mm) |
150*237*79 |
