ES Series
Floor-Standing Lithium Battery
The ES Series floor-standing lithium battery is designed for higher-capacity home and small commercial energy storage. Built with LiFePO4 cells, it supports up to 15 units in parallel, features up to 200A discharge capability, and delivers more than 8,000 cycles for long-term, reliable energy use.
ES Series

Advantages

01 Lithium iron phosphatebattery,safer
02 Supports up to 15 units in parallel
03 Max.discharge:200 A
04 ≥8000 cycles
05 Advanced BMS management
06 Compatible with mainstream inverters
ES Series

Technical Specifications

ES Series
ES16.08
Rated Voltage 51.2VDC
Rated Capacity 314Ah
Rated Energy(Wh) 16076
Rated Charge Current@RT 100A
Rated Discharge Current@RT 100A
IP Grade IP21
Dimension(unit) L*W*H(mm) 475*350*907
Weight (N.W.) 150kgs
ES10.24
Rated Voltage 51.2VDC
Rated Capacity 200Ah
Rated Energy(Wh) 10240
Rated Charge Current@RT 200A
Rated Discharge Current@RT 100A
IP Grade IP31/IP54
Dimension(unit) L*W*H(mm) 575*350*675
Weight (N.W.) 100kgs
ES16.08
Rated Voltage 51.2VDC
Rated Capacity 314Ah
Rated Energy(Wh) 16076
Rated Charge Current@RT 100A
Rated Discharge Current@RT 200A
IP Grade IP31/IP54
Dimension(unit) L*W*H(mm) 475*350*907
Weight (N.W.) 150kgs
ES10.24
Rated Voltage 51.2VDC
Rated Capacity 200Ah
Rated Energy(Wh) 10240
Rated Charge Current@RT 100A
Rated Discharge Current@RT 100A
IP Grade IP21
Dimension(unit) L*W*H(mm) 575*350*675
Weight (N.W.) 100kgs
