Vehicle-mounted Energy Storage

RV Solution

Charge Controller

DMP25/DMP50

DCDC+MPPT charging controller

DMP25/DMP50

The DMP25/DMP50 DCDC+MPPT Charging Controller combines DC/DC and MPPT charging in one intelligent unit. It automatically detects input voltage, adjusts charging load, supports lithium, lead-acid and gel batteries, and uses temperature monitoring plus multiple protections to ensure reliable RV power supply in demanding environments.

Request a Quote

Advantages

01 Wide Input Voltage Range

02 High Input Power Capacity

03 Up to 95% Conversion Efficiency

04 Multiple Protection Mechanisms

05 Integrated MPPT Technology

06 Smart LCD Monitoring

Technical Specifications

DMP25 / DMP50

DMP50 12V

(1) Starter Battery -Not using “IGNITION”
Voltage Range	10.5-16
Normal Starting Voltage	>13.5
(2) Solar Array
Voltage Range	14.5-45VDC
Maximum Power	600W/800W
(3) RV Battery
Output Voltage	23-29
Output Power	775W
Efficiency	95%
Remote Communication	CAN
(4) Starter Battery - Using “IGNITION”
Normal Starting Voltage	>12.5

DMP50 24V

(1) Starter Battery -Not using “IGNITION”
Voltage Range	21-32Vdc
Normal Starting Voltage	>26.4
(2) Solar Array
Voltage Range	14.5-45Vdc
Maximum Power	600/800W
(3) RV Battery
Output Voltage	23-29
Output Power	710W
Efficiency	95%
(4) Starter Battery - Using “IGNITION”
Normal Starting Voltage	>24.6

DMP25 12V

(1) Starter Battery -Not using “IGNITION”
Voltage Range	10.5-16
Normal Starting Voltage	>13.5
(2) Solar Array
Voltage Range	14.5-45
Maximum Power	600/800W
(3) RV Battery
Output Voltage	13.8-15.5
Output Power	775W
Efficiency	95%
Remote Communication	CAN
(4) Starter Battery - Using “IGNITION”
Normal Starting Voltage	>12.5

DMP25 24V

(1) Starter Battery -Not using “IGNITION”
Voltage Range	21-32
Normal Starting Voltage	>26.4
(2) Solar Array
Voltage Range	14.5-45
Maximum Power	600/800W
(3) RV Battery
Output Voltage	23-29
Output Power	710W
Efficiency	95%
Remote Communication	CAN
(4) Starter Battery - Using “IGNITION”
Normal Starting Voltage	>24.6
