6000W Pure Sine Wave Inverter Charger

CPT series 6000W

6000W Pure Sine Wave Inverter Charger - CPT6K

Sample Title

Sample Text

6000W Pure Sine Wave Inverter Charger - CPT6K

Sample Title

Sample Text

6000W Pure Sine Wave Inverter Charger - CPT6K

Sample Title

Sample Text

6000W Pure Sine Wave Inverter Charger - CPT6K

Sample Title

Sample Text

  1. 6000W Pure Sine Wave Inverter Charger - CPT6K
  2. 6000W Pure Sine Wave Inverter Charger - CPT6K
  3. 6000W Pure Sine Wave Inverter Charger - CPT6K
  4. 6000W Pure Sine Wave Inverter Charger - CPT6K
Ref: CPT6K
● DC/AC source auto switch: Inverter works by DC source to power the loads, and will switch to AC utility as soon as nominal AC powr source is connected. When AC power is removed, inverter will switch to DC power source to keep all the loads continuously working

● Pure sine wave output: For motored loads or sensitive loads operation

● Built-in three-stage battery charger: with compatibility of Lithium/Gel/AGM/Wet battery recharges most batteries quickly while prevent them from being overcharged

● Gen starter: Deliver boost signal to start backup generator for emergency
Would you like to know more?
Wholesale Enquiry

Features

With the pure sine wave output, no matter coffee machine, microwave, TV, satellite, printer, or other equipment, the CPT inverter charger gives the perfect performance for running loads from household appliances to office devices.

Lithium battery compatibility gives another option for the house battery. Batteries are charged quickly and safely by the input utility power or vehicle generator. The automatic protect function ensures the battery banks from being over-discharged/charged. The CPT inverter charger guarantees the interrupted power supply with an auto transfer switch.

Product Features
● Approved by ETL under UL458 and CSA C22.2, CE under EN55022:2006+A1:2007 standards
● Pure sine wave output runs all loads from households appliances to office equipment
● Built-in three-stage battery charger with the compatibility of Lithium/Gel/AGM/Wet battery
recharges most batteries quickly while preventing them from being overcharged
● Internal transfer switch transfers between DC power and utility power
● External LCD remote controller-PTM12 or re-programmable interactive monitor control system
-CR80 for easy data read and better references
● Gen starter gives boost signal to start back up generator for emergency
● Tool-free battery connection terminal for easy installation and DC short-circuit defending
● 18 months warranty
Protection
● Input AC over-voltage and low voltage protection
● Battery DC over voltage and low voltage protection
● Short circuit protection
● Over temperature protection

● Overload protection


Models CPT6000
output power 6000W
SurgePower 18000W
DCInputVoltage 24VDC/48VDC
OutputVoltage

100/110/120VAC±5%;220/230/240VAC±3%;

120/240VACSplitphase

OutputFrequency 50/60Hz±0.5%
OutputWaveform pure sinewave(THD<5%)
Idleconsumption(Savingmodel/workingmodel) 9W/30W
AC input frequency 50/60Hz±0.5%
Efficiency 110VAC 86%
230VAC 87%
transfer time <8ms
ACInputRange 90~135VAC/190~245VAC
DCVoltageRange 20.0-31.0/42.0-62.0VDC
ACCharger/Bypass
DCoutputvoltage
Bulk(13.0-14.9V);Absorption(14.9-15.1V);
Floatcharge(13.3-13.8V)(24V*2,48V*4)
Overcharge protection 15.7VDC(24V*2,48V*4)
Chargecurrent 110VAC 75A/50A
230VAC 75A/50A
Transfer time <10ms
Inputwaveform Puresinewave(Utilitypowerorgenerator)
MAXbypasscurrent 40A
Control&Signal
LEDindicator 7-ledforworkingmode
Remotecontrol(optional) CR10;PTM-12
Dipswitch Chargecurrent;Outputfrequency;ACoutputvoltage;DC/ACpriority
Networkfunction Stand-alone,orTCP/IPoptional
Batterytype Lithium,Gel,AGM,Wetorcustomized
Drycontactterminal Byrelay
GeneralSpecification
Safety UL458,LVD(EN60950)
EMC FCCpart15ClassA,CE(EN55022:2006+A1:2007)
Operating/Storagetemp -20-50℃/-30-70℃
Working humidity -20-90%RH
Weight(Kg/Ib) 45/99
Dimension(mm/inch) 650*250*185/26*10*7
Application
The vehicle, Yacht, Solarpowersystems, Portableequipment,
Powertools, HomeandOfficeappliances
